About this product
Vortex® Precision Riflescope Rings are kept in pairs throughout the manufacturing process ensuring perfection from one set to another. These rings are held to an extremely tight tolerance of .0005″ and are serialized, vibratory tumbled, hand-bead blasted, and anodized with Type III hard coat.
Manuals & parts PMR_34_92 Parts Diagram (PDF) (512.59 kB) Instruction Card (PDF) Specifications
| Tube Size | 34mm |
|---|---|
| Ring Height | .92 inches |
| Center Scope Height | 0.92″ |
| Weight | 2.3 oz. per ring |
| Cap Screw Torque | 15-18 in-lbs. |
| Base Screw Torque | 45-50 in-lbs. |
